M8761BT3 1T1R B5.0 Module

Introduction

The BL-M8761BT3 is a highly integrated Bluetooth 5.0 module with a UART interface designed base on Realtek RTL8761BTV-VAT. It combines a BT Protocol Stack (LM, LL, and LE), BT baseband, modem, and BT RF. The RTL8761BTV-VAT Bluetooth controller complies with Bluetooth core specification v5.0, and supports dual mode (BR/EDR + Low Energy Controllers). It is compatible with previous versions, including v2.1 + EDR. For BR/EDR, it allows multiple active links in either slave mode or master mode. For Low Energy, it supports multiple states and allows multiple active links in slave mode. The links in BR/EDR and LE can be active simultaneously.

Features

Bluetooth 5 specification compliant, supports BDR/EDR/BLE

Complies with HS-UART with configurable band rate

Connect to external antenna through the half hole

Power Supply: VDD3.3V±0.2V

Block Diagram

General Specifications

Product Dimension

Module dimension: 15.0*13.0*1.7mm (L*W*H; Tolerance: ±0.3mm_L/W, ±0.2mm_H)

Package Dimensions
