BL-M8761BU2
LB-LINK
V5.0
REALTEK
1T1R
USB2.0 Interface
Introduction
BL-M8761BU2 BT5 USB module is designed base on RTL8761BUV, It combines a BT Protocol Stack (LM, LL, L2CAP, GATT, RFCOMM, SPP, and LE), BT Baseband, modem and BT RF in a single chip. The BL-M8761BU2 BT5 USB module complies with Bluetooth core specification v5 and supports dual mode (BR/EDR + Low Energy Controllers). It is compatible with previous versions, including v2.1 + LE. For BR/EDR, it allows multiple active links in either slave mode or master mode. For Low Energy, it supports multiple states and allows multiple active links in slave mode. A BR/EDR link and an LE link can be active at the same time.
Features
Bluetooth 5.0 Dual Mode support: Simultaneous LE and BR/EDR
USB1.1 full speed for Bluetooth controller
Supports Bluetooth Low Energy(BLE)
Supports Bluetooth classic(BDR/EDR)
Supports Bluetooth PCM
Connect to external antenna through half hole
Block Diagram
Module Name | BL-M8761BU2 |
Chipset | RTL8761BUV-CG |
Bluetooth Standards | Bluetooth Core Specification v5.0 |
Operating Frequencies | 2.402~2.480GHz |
Host Interface | USB1.1 full speed for Bluetooth |
Antenna | Connect to the external antenna through half hole pad |
Dimension | 12.9*12.2*1.7mm |
Power Supply | |
Operation Temperature | -20℃ to +70℃ |
Operation Humidity | 10% to 95% RH (Non-Condensing) |
Product Dimension
Module dimension: 12.9*12.2*1.7mm (L*W*H; Tolerance: ±0.15mm)
1. 2,000 modules per roll and 10,000 modules per box.
2. Outer box size: 37.5*36*29cm.
3. The diameter of the blue environment-friendly rubber plate is 13 inches, with a total thickness of 28mm
(with a width of 24mm carrying belt).
4. Put 1 package of dry agent (20g) and 1 humidity card in each anti-static vacuum bag.
5. Each carton is packed with 5 boxes.
