M7920XU1 2T2R 802.11a/b/g/n/ac/ax WiFi+B5.3 Module

  • MT7920TUN
  • USB 3.0
  • 2.4/5GHz
  • 1201Mbps
  • 2x2 2T2R
  • 27*17.8*2.4mm
Availability:
Quantity:
  • BL-M7920XU1

  • LB-LINK

  • V5.3

  • MTDIATEK

  • 2T2R

  • USB3.0 Interface

  • Wi-Fi 6 (802.11ax)

Double Your Network Capabilities with Dual USB WiFi Modules


Introduction

BL-M7920XU1 is a highly integrated Dual-band WLAN + Bluetooth v5.3 Combo module. It combines a 2T2R Dual-band WLAN subsystem and a Bluetooth v5.3 subsystem, This module compatible IEEE 802.11 a/b/g/n/ac/ax standard and provides the maximum PHY rate up to 1200Mbps, it supports BT / BLE dual mode with BT v5.3/v4.2/v2.1 compliant, offering feature-rich wireless connectivity at high standards, and delivering reliable, cost-effective throughput from an extended distance.



Features

Operating Frequency: 2.4~2.4835GHz or 5.15~5.85GHz

IEEE Standards: IEEE 802.11a/b/g/n/ac/ax

Wireless PHY rate can reach up to 1200Mbps

Support BT Classic / BT Low Energy dual mode

DC 3.3V±0.2V main power supply



Block Diagram

截屏2024-06-14 14.39.57



General Specifications


Module Name

BL-M7920XU1

Chipset

MT7920TUN

WLAN Standards

IEEE 802.11 a/b/g/n/ac/ax

BT Specification

Bluetooth Core Specification v5.3/4.2/2.1

Host Interface

USB3.0/USB2.0 for WLAN & Bluetooth

Antenna

Connect to the external antennas through IPEX connectors

Half hole PADs for external BT antenna (Reserved IPEX connector for BT)

Dimension

27.0*17.8*2.4mm (L*W*H)

Power Supply

DC 3.3V±0.2V @1200mA (Max)

Operation Temperature

-20℃ to +70℃

Operation Humidity

10% to 95% RH (Non-Condensing)




Product Dimension

截屏2024-06-14 14.40.08

Module dimension: 27.0mm*17.8mm*2.4mm (L*W*H; Tolerance: ±0.3mm_L/W, ±0.2mm_H)

IPEX / MHF-1 connector dimension: 3.0*2.6*1.2mm (L*W*H, Ø2.0mm)



Package Dimensions

图片 1

图片 12


Package specification:

1. 900 modules per roll and 3,600 modules per box.

2. Outer box size: 39.5*38*35cm.

3. The diameter of the blue environment-friendly rubber plate is 13 inches, with a total thickness of 48mm

    (with a width of 44mm carrying belt).

4. Put 1 package of dry agent (20g) and humidity card in each anti-static vacuum bag.

5. Each carton is packed with 4 boxes.
