M8801MS4G 1T1R 802.11b/g/n WiFi Module

  • 88W8801B0-NMDI/AZ
  • SDIO
  • 802.11b/g/n
  • 2.4GHz
  • 72.2Mbps
  • 1x1 1T1R
  • 13*13.5*2mm
Availability:
Quantity:
  • BL-M8801MS4G

  • LB-LINK

  • Without BT

  • WuQi

  • 1T1R

  • SDIO Interface

  • Wi-Fi 4 (802.11n)

Introduction

BL-M8801MS4 product is designed base on MARVELL 88W8801.  It operates at 2.4~2.4835GHz and supports IEEE 802.11b/g/n 1T1R with High Throughput data rate for WLAN products. It also supports IEEE802.11i safety protocol, along with IEEE 802.11e standard service quality.  The module provides a SDIO interface accord with SDIO 1.1/2.0, and bring about stable, high rate, long distance wireless connectivity through external antenna. It can implement the wireless network function on the laptop/desktop/MID and other wireless devices easily.




Features

  • Operating Frequencies: 2.4~2.4835GHz

  • Host Interface :SDIO 2.0 for WLAN

  • Wireless PHY rate up to 72.2Mbps

  • 3.3V main power and 3.3V I/O power



Block Diagram




General Specifications


Module   Name

BL-M8801MS4G

Chipset

88W8801B0-NMDI/AZ

WLAN   Standard

IEEE   802.11 b/g/n

Host   Interface

SDIO 2.0 for WLAN

Antenna

Connect to the external antenna   through half hole

Dimension

13.0*13.5*2.0mm   (L*W*H)

Power   Supply

DC 3.3V±0.2V @ 360 mA (Max)

Operation   Temperature

-40℃ to +85℃

Operation   Humidity

10% to   95% RH (Non-Condensing)



Product Dimension



Module dimension: 13.0*13.5*2.0mm(L*W*H; Tolerance: ±0.3mm_L/W, ±0.2mm_H)



Package Dimensions



Package specification:

1. 150 modules per blister plate and 3,000 modules per box.

2. The blister is bound with wire membrane and put into anti-static vacuum bag.

3. Put 1 bag of dry beads (20g) and 1 humidity card in each anti-static vacuum bag.

4. The outer box size is 35.2*21.5*15.5cm.
